TITAN LIQUILIZER

Description

The TITAN-12000 liquilizer is a unit for high-precision intra-soil application of liquid complex fertilizers, UAS, bifungucides, insecticides.. The main purpose of intra-soil application of complex liquid fertilizers is an effective solution for obtaining stable and high crop yields, as well as reducing the degree of dependence on weather conditions.

Reinforced frame. When manufacturing the frame of the TITAN-12000 liquilizer, a thick-walled profile pipe made of 09G2S structural steel is used;
Hydraulic folding system in the transport position up to three meters wide;

Reinforced frame. When manufacturing the frame of the TITAN-12000 liquilizer, a thick-walled profile pipe made of 09G2S structural steel is used;

Filling capacity of 4 cubic meters.
Clean water tank with a volume of 330 liters, for washing the tank and the entire system of the unit
Rotation of the liquid pump, with a capacity of 135 l / min, is carried out using a hydraulic motor.
The needles are made of stainless steel with special heat treatment and are highly reliable
The wheels of the liquilizer are made of stainless steel and are characterized by high wear resistance
The spring-loaded suspension of the liquilizer wheel struts protects the working parts of the liquilizer from breakage when maneuvering and copying the soil relief

РАМА

		Усиленная рама. При производстве рамы ликвилайзера серии TITAN применяется толстостенная профильная труба из конструкционной стали 09Г2С;


		Гидравлическая система складывания в транспортное положение до трех метров по ширине;

		Централизованная система смазки всех шарнирных соединений рамы и рабочих органов.

РАБОЧИЕ ОРГАНЫ

		Заправочная ёмкость объемом 4 м.куб.


		Ёмкость для чистой воды обьёмом 330л., для промывки ёмкости и всей системы агрегата


		Вращение жидкостной помпы, производительностью 135 л/мин, осуществляется с помощью гидравлического мотора.


		Иглы изготовлены из нержавеющей стали со специальной термообработкой, отличаются высокой надежностью Колеса ликвилайзера выполнены из нержавеющей стали , отличаются высокой износостойкостью
		Шарнирная подвеска стоек колес ликвилайзера на подпружиненной основе защищает от поломки рабочие органы ликвилайзера при маневрировании и копировании рельефа почвы

Specifications

Parameter	TITAN-9000	TITAN-12000	TITAN-15000
Unit Type	semi-trailer	semi-trailer	semi-trailer
Weight, kg	6600±200	7600±200	8600±200
Working speed, km / h	Up to 8
Maximum transport speed, km / h, max	20
Overall dimensions in transport position
Width, mm	2950±50	2950±50	3800±50
Height, mm	3500±200	3800±200	3800±200
Length, mm	8800±500
Overall dimensions in working position
Width, mm	8850±50	11850±50	14850±50
Height, mm	3500±500
Length, mm	8800±500
Ground clearance, mm	300
Three-point suspension category	3
Tire size	700-50R22. 5 or 600-50R22. 5
Filling tank capacity, l	4000
Volume of washing tank, l	330
Number of personnel required for service by profession, people	1 machine operator
Rate of material application (PG, CAS or HCS), l / ha	50...500
Nominal pressure in the hydraulic system, Mpa	16
Number of disks, pcs	36	48	60
Number of needles per disk, pcs	12	12	12
Distance between injection points, mm	170	170	170
Distance between disks, mm	250	250	250
Fertilizer application depth, cm	up to 7	up to 7	up to 7
Maximum disk load, kg	170	170	170
Technical characteristics of the MR-50C hydraulic motor:
Working volume, cm3	51,5
Inlet pressure:
Nominal Pressure, Mpa	16
Maximum Pressure, Mpa	20
Speed of rotation, S-1	550
Nominal value, S-1	775
Maximum, S-1	100
Torque, N*m	8,3
Rated power, kW	5,6
