Mounted Swathing Tedder Rakes of GVV-6.0N Albatross series
The GVV-6.0N “A” swathing tedder rake is a mounted unit that can perform one of the three following operations depending on the application conditions and component parts: tedding dried grass in swaths, raking the grass from the swaths into windrows and turning the windrows.
The rakes are used in all agro-climatic zones, on all soil types, except for stony ones. The application of the rakes is effective for harvesting sown grasses and natural hayfields with a yield of more than 10 dt/ha on the plains at the mass moisture of 25-80%.
The rakes are aggregated with the tractor hitch with the motor power of 60-80 h.p.
Sound PRO! arguments for the GVV-6.0N “A” rakes:
• The mounted structure is easily fastened to the hinged device of the tractor, as well as easily transformed into the working and transport positions;
• The running wheel is mounted on a hub with 2 bearings ensuring its continuous operation free of maintenance;
• The hub assembly of the running wheel is made of high quality materials and has a large margin of safety and increased wear resistance;
• The spring unit of the running wheels allows to copy the soil relief with high accuracy, while reducing losses, as well as simplifies the rake transformation from the raking mode into the tedding one and vice versa;
• Affordable price with the high quality of performance;
• High maneuverability thanks to compact dimensions.
Parameter name |
GVV-6,0N«А» |
|
Operating width, m |
6 |
|
Productivity, ha/hour |
8,4 |
|
Number of working wheels, pcs. |
8 |
|
Diameter of working wheels, mm |
1450 |
|
Diameter of spring pin, mm |
7 |
|
Operating speed, km/h, not more than |
20 |
|
Transport speed, km/h, not more than |
20 |
|
Dimensions when raking, mm: |
length |
3100 |
width |
6000 |
|
height |
1500 |
|
Dimensions when turning, mm: |
length |
3100 |
width |
7200 |
|
height |
1500 |
|
Dimensions in the transport position, mm: |
length |
3200 |
width |
2800 |
|
height |
3300 |
|
Weight, kg |
440 |
|
Service life, years |
7 |
|
Number of operating staff, persons |
1 |
|
Recommended drawbar category of tractors, p.f. |
0,6-1,4 |
